Panels - Nora Lighting

NPDBLSW-E14

kevin.solano — Thu, 09 Jun 2022 18:42:41 +0000

LED Backlit can be utilized in offices, conference rooms, libraries and other tasks areas where general illumination is desired. White opalescent diffused lens optimizes output while reducing LED diode image. Panels are sold and packaged in quantities of two.

FEATURES
• Field Selectable Lumens
• Field Selectable CCT
• Fits most grid ceilings
• Surface, Pendant and Hard ceiling recessed kits available
• Dimmable with compatible 0-10V dimmer
• 120-347V
• DLC Listed

Lumens / Wattage: Up to 3650lm / 30W

Color Temperature: Field Selectable (3000K / 3500K / 4000K)

Finish: White

Accessories:
NPDBL-JB4X4 = 4' Junction box for daisy chaining
NPDBL-14DFK = Surface Mount Frame
NPDBL-14RFK = Recessed Mounting Kit
NPDBL-PKW = Pendant Mounting Kit

The post NPDBLSW-E14 first appeared on Nora Lighting.

NPDBLSW-E24

kevin.solano — Thu, 09 Jun 2022 18:42:39 +0000

Lumens / Wattage: Up to 5700lm / 45W

Color Temperature: Field Selectable (3000K / 3500K / 4000K)

Finish: White

Accessories:
NPDBL-JB4X4 = 4' Junction box for daisy chaining
NPDBL-24DFK = Surface Mount Frame
NPDBL-24RFK = Recessed Mounting Kit
NPDBL-PKW = Pendant Mounting Kit

The post NPDBLSW-E24 first appeared on Nora Lighting.

NPDBLSW-E22

kevin.solano — Thu, 09 Jun 2022 18:23:45 +0000

FEATURES
• Field Selectable Lumens
• Field Selectable CCT
• Fits most grid ceilings
• Surface, Pendant and Hard ceiling recessed kits available
• 120-347V input; 0-10V dimming
• DLC Listed

Lumens / Wattage: Up to 3750lm / 30W

Color Temperature: Field Selectable (3000K / 3500K / 4000K)

Finish: White

Accessories:
NPDBL-JB4X4 = 4' Junction box for daisy chaining
NPDBL-22DFK = Surface Mount Frame
NPDBL-22RFK = Recessed Mounting Kit
NPDBL-PKW = Pendant Mounting Kit

The post NPDBLSW-E22 first appeared on Nora Lighting.

NPDBL-24DDFK

izzyalf — Thu, 23 Sep 2021 22:23:00 +0000

2' x 4' Frame mounts over an existing junction box and panel slides into place. Surface frame extends only 4.33" from the ceiling. Not compatible with pendant kit.

Compatible Panels:
NPDBL-E22 = 2' x 4' LED Backlit Panel with Emergency
NPDBLSW-E22 = 2' x 4' LED Backlit Panel w/ Selectable Lumens & CCT and Emergency

Compatible Pendant Kits:
NPDBL-PK/W = Pendant Kit, White Finish

Dimension:
Width: 24"
Length: 48"
Height: 4.33"

Finish: White

The post NPDBL-24DDFK first appeared on Nora Lighting.

NPDBL-22DDFK

izzyalf — Thu, 23 Sep 2021 22:22:58 +0000

2' x 2' Frame mounts over an existing junction box and panel slides into place. Surface frame extends only 4.33" from the ceiling. Not compatible with pendant kit.

Compatible Panels:
NPDBL-E22 = 2' x 2' LED Backlit Panel with Emergency
NPDBLSW-E22 = 2' x 2' LED Backlit Panel w/ Selectable Lumens & CCT and Emergency

Compatible Pendant Kits:
NPDBL-PK/W = Pendant Kit, White Finish

Dimension:
Width: 24"
Length: 24"
Height: 4.33"

Finish: White

The post NPDBL-22DDFK first appeared on Nora Lighting.

NPDBL-14DDFK

izzyalf — Thu, 23 Sep 2021 22:16:18 +0000

1' x 4' Frame mounts over an existing junction box and panel slides into place. Surface frame extends only 4.33" from the ceiling. Not compatible with pendant kit.

Compatible Panels:
NPDBL-E14 = 1' x 4' LED Backlit Panel with Emergency
NPDBLSW-E14 = 1' x 4' LED Backlit Panel w/ Selectable Lumens & CCT and Emergency

Dimension:
Width: 12"
Length: 48"
Height: 4.33"

Finish: White

The post NPDBL-14DDFK first appeared on Nora Lighting.

NPDBL-14DFK

izzyalf — Wed, 19 May 2021 21:49:05 +0000

1' x 4' Frame mounts over an existing junction box and panel slides into place. Surface frame extends only 2.5" from the ceiling. May be used in combination with pendant kit for a complete finished appearance.

Compatible Panels:
NPDBL-E14 = 1' x 4' LED Backlit Panel
NPDBLSW-E14 = 1' x 4' LED Backlit Panel w/ Selectable Lumens & CCT

Compatible Pendant Kits:
NPDBL-PK/W = Pendant Kit, White Finish

Dimension:
Width: 12"
Length: 48"
Height: 2.5"

Finish: White

The post NPDBL-14DFK first appeared on Nora Lighting.

NPDBL-22DFK

izzyalf — Wed, 19 May 2021 21:49:04 +0000

2' x 2' Frame mounts over an existing junction box and the panel slides into place. The surface frame extends only 2.5" from the ceiling. May be used in combination with a pendant kit for a complete finished appearance.

Compatible Luminaires:
NCSP-22: 2' x 2' Contractor Series Backlit Panels with Selectable Lumens & CCT
NPDBL-E22: 2' x 2' LED Backlit Panel
NPDBLSW-E22: 2' x 2' LED Backlit Panel with Selectable Lumens & CCT

Compatible Pendant Kits:
NPDBL-PK/W: Pendant Kit, White Finish

Dimension:
Width: 24"
Length: 24"
Height: 2.5"

Finish: White

The post NPDBL-22DFK first appeared on Nora Lighting.

NPDBL-24DFK

izzyalf — Wed, 19 May 2021 21:48:31 +0000

2' x 4' Frame mounts over an existing junction box and the panel slides into place. The surface frame extends only 2.5" from the ceiling. May be used in combination with a pendant kit for a complete finished appearance.

Compatible Luminaires:
NCSP-24: 2' x 4' Contractor Series Backlit Panels with Selectable Lumens & CCT
NPDBL-E24: 2' x 4' LED Backlit Panel
NPDBLSW-E24: 2' x 4' LED Backlit Panel with Selectable Lumens & CCT

Compatible Pendant Kits:
NPDBL-PK/W: Pendant Kit, White Finish

Dimension:
Width: 24"
Length: 48"
Height: 2.5"

Finish: White

The post NPDBL-24DFK first appeared on Nora Lighting.

NPDBL-JB4X4

kevin.solano — Tue, 25 Aug 2020 00:00:44 +0000

4" Junction box for LED Backlit Panels. Junction box mounts on panel to allow them be daisy chained together on the same switch (4-in / 4-out)

Compatible Luminaires:
NCSP-22: 2' x 2' Contractor Series Backlit Panels with Selectable Lumens & CCT
NCSP-24: 2' x 4' Contractor Series Backlit Panels with Selectable Lumens & CCT
NPDBL-E22: 2' x 2' LED Backlit Panels
NPDBLSW-E22: 2' x 2' LED Backlit Panels with Selectable Lumens & CCT
NPDBL-E24: 2' x 4' LED Backlit Panels
NPDBLSW-E24: 2' x 4' LED Backlit Panels with Selectable Lumens & CCT
NPDBL-E14: 1' x 4' LED Backlit Panels
NPDBLSW-E14: 1' x 4' LED Backlit Panels with Selectable Lumens & CCT

The post NPDBL-JB4X4 first appeared on Nora Lighting.
